| Pixel pitch | PH2.5 | ||
| Module Parameters | Pixel pitch | 2.5mm | |
| Pixel Density | 160000pixels/m2 | ||
| LED Shape | SMD | ||
| LED Configuration | 1R1PG1B | ||
| Module Resolution | 128*64 | ||
| Module Size | 320mm*160mm | ||
| Drive Method | Constant Current 1/32 | ||
| Cabinet Parameters | Cabinet Resoltuion | 256*128 | |
| Cabinet Size | 640*480*80 mm | ||
| Cabinet Weight | 13kg | ||
| Display Parameters | Optical | Brightness | <1000cd/m2 |
| Viewing angle | H/V 160/160 | ||
| Best Viewing Distance | 2-35 m | ||
| Display Color | 16.7 million | ||
| Grey Scale | 16bits/1024levels | ||
| Power | Max power consumption | 800 W/m2 | |
| Ave power consumption | 300 W/m2 | ||
| Working Voltage | 220V / 110V | ||
| Control system | Frame Frequency | 60--85 HZ | |
| Refresh Rate | 1920 HZ | ||
| Data Transmission | CAT 5/ Optic Fiber | ||
| Image Source | S-Video, PAL/ NTSC | ||
| Controlling system | linsn, Nova, Mooncell, ZD, Xixun, | ||
| Lumen, Dbstar | |||
| Format | Video Compatibility DVI, VGA, composite | ||
| Reliability | Working Temperature | -20~65 °C | |
| Working Humidity | 10-90% RH | ||
| Life Span | 100,000 Hours | ||
| MTBF (Ave No Faliure Time) | 5000 Hours | ||
| Pixel failing Rate | 0.01% | ||
| IP Rate | IP 54 | ||
