Colorfull P5 P4 P3.076 P2.5 LED Screen Wall Indoor Wedding Stage
LED Screen Wall Indoor Wedding Stage

INDOOR P2.5 P3.076 P4 P5 SMD 3IN1 TECHNICAL PARAMETERS
Unit ModuleItemParameterParameterParameterParameter
Model NumberHM-PH2.5-32SHM-PH3.076-26SHM-PH4-20SHM-PH5-16S
Module size320mm*160mm320mm*160mm320mm*160mm320mm*160mm
Pixel pitch2.5mm3.076mm4mm5mm
Pixels Density160000dots/m2105688dots/m262500dots/m240000dots/m2
Pixel configuration1R1G1B1R1G1B1R1G1B1R1G1B
Package modeSMD2121SMD2020SMD2121SMD2121
Pixel resolution128dots(W)*64dots(H)104dots(W)*52dots(H)80dots(W)*40dots(H)64dots(W)*32dots(H)
Drive typeConstant driveConstant driveConstant driveConstant drive
Scan mode1/32scan1/26scan1/20scan1/16scan
Port typeHUB75HUB75HUB75HUB75
Brightness of white balance≥1200cd/m2≥1100cd/m2≥1500cd/m2≥1500cd/m2
LED Display CabinetDimension640mm*640mm640mm*640mm640mm*640mm640mm*640mm
Monomer Module Number8888
Pixel per cabinet256*256dots208*208dots160*160dots128*128dots
Power supply5V60A*1PC5V60A*1PC5V60A*1PC5V60A*1PC
Best viewing distance3M~25M3M~30M4M~40M5M~50M
Best viewing angle160°(W) 120°(H)160°(W) 120°(H)160°(W) 120°(H)160°(W) 120°(H)
Temperaturestorage:-35ºC~+85ºCstorage:-35ºC~+85ºCstorage:-35ºC~+85ºCstorage:-35ºC~+85ºC
working:-20ºC~+50ºCworking:-20ºC~+50ºCworking:-20ºC~+50ºCworking:-20ºC~+50ºC
Relative humidity10%-95%10%-95%10%-95%10%-95%
PowerWorking voltageAC110~220V±10%AC110~220V±10%AC110~220V±10%AC110~220V±10%
Average Power consumption≤300W/m2≤300W/m2≤300W/m2≤300W/m2
Max.Power consumption≤600W/m2≤600W/m2≤600W/m2≤600W/m2
Current≤20mA(single LED)≤20mA(single LED)≤20mA(single LED)≤20mA(single LED)
Control SystemCPUPentium4 or above Pentium4 or above Pentium4 or above Pentium4 or above
Operation systemWIN98/2000/NT/XP/WIN7WIN98/2000/NT/XP/WIN7WIN98/2000/NT/XP/WIN7WIN98/2000/NT/XP/WIN7
Control methodSynchronous and asynchronousSynchronous and asynchronousSynchronous and asynchronousSynchronous and asynchronous
Main Technical ParameterDriving deviceConstant drive ICConstant drive ICConstant drive ICConstant drive IC
Refresh frequency≥1200HZ≥1200HZ≥1200HZ≥1200HZ
Grey scale/colors4096gray level/16.7M colors4096gray level/16.7M colors4096gray level/16.7M colors4096gray level/16.7M colors
MTBF≥100000hours≥100000hours≥100000hours≥100000hours
Power switchAutomatic switchAutomatic switchAutomatic switchAutomatic switch
Display Mode≥800*600/1024*768≥800*600/1024*768≥800*600/1024*768≥800*600/1024*768
LED Screen Wall Indoor Wedding StageLED Screen Wall Indoor Wedding Stage
LED Screen Wall Indoor Wedding Stage
LED Screen Wall Indoor Wedding Stage
LED Screen Wall Indoor Wedding Stage
LED Screen Wall Indoor Wedding StageLED Screen Wall Indoor Wedding Stage


LED Screen Wall Indoor Wedding Stage
LED Screen Wall Indoor Wedding Stage

FAQ
Q1: What is the warranty for the led display?
A1:Normally we will provide customers 2 -3 years warranty and long term technology support and after-service.
Q2: How do you ensure the quality
A2: We get three QC processes:1.For raw materials;2.During the half of production; 3.Final QC test one by one after aging 12 hours.
Q3: How to do if any quality problems on our side in the warranty time?
A3: In usually every screen we will be ready more extra led screen modules as spare modules, if some modules happen fails, you can replace the fail modules by our spare modules,
When all the spare modules use out, You can send back these modules for us to repair, and we will send to you after repair and testing&aging well
.
Q4: OEM OR ODM accepted?
A4:Yes,we can do OEM & ODM,logo on the light or package both are available.
Q5: Which refresh rate for the led display you can provide?
A5:the maximum refresh rate can be achieved more than 3840Hz. Also we can provide the normally refresh rate if you need.
Q6:  How many days will samples be finished?And how about the mass production?
A6: Generally 5-7 days for samples making. The leading time of mass production will depend on the quantity.
