Outdoor P10 LED display Full Color LED modules led screens


LED Screen Technical Parameters

LED Lamp
Chip parametersRed (620-625nm) IV: (800-960mcd )
Chip parametersGreen (520-525nm) IV: (1350-1650mcd)
Chip parametersBlue (470-475nm) IV: (330-400mcd)
LED Module
Pixel Pitch10mm
Module Size320×160
Module Resolution32×16=512(Dots)
Module Weight0.5kg
LED Cabinet
Pixel Density10000 Dots/sqm
Cabinet Dimension(W*H*D)960×960×130mm
Cabinet Resolution96×96=9216(Dots)
Module Quanty /Cabinet6×3=18(PCS)
Cabinets MaterialSteel Or Iron
Cabinet Weight41kg
Non-FlatnessLess than 0.5mm
Module intervalLess than 0.5mm
Color temperature6500-8000K
Viewing Angle120(Horizontal), 120(Vertical)
Nearest Viewing Distance13m
Power Consumption (Max)1000 w/sqm
Power Consumption (Average)300 w/sqm
Refresh Rate>1000Hz
Drive Mode/Driver PositionConstant driving 1/4 Scan, Combined diver board
Display FunctionText, Graphics, Video
Frame FrequencyNo less than 60 frame/sec
Input VoltageAC110-220V±10%, 50/60Hz
Output VoltageDC-5V, 40A/60A/80A
Color Grayscale16bit
Color ProcessingR(1024)×G(1024)×B(1024)
Brightness Adjustment256 color levels, can be adjusted manually and automatically optional
MTBF( mean time between failures)5000 hours
Life-span100, 000 hours
Protection Level(front/back)IP66/IP54
Malfunction DOT RateLess than 0.0001
Working Temperature-30oC-50oC
Control System
Control ModeSynchronization/Asynchronization
Control SystemSending Card, Receiving Card, Receiving HUB
SoftwareLED Studio (FWS-linsn)
LanguageChinese, Traditional Chinese, English, French, Japanese, Russian, Thai, Spanish, Polish, Italian, Portuguese, Turkish, Dutch, Greek, Bulgarian, Romanian, Arabic, Korean, German,
Control Card InputDVI, USB; RJ45, HDMI(Sold separately)
Input SignalAVI/MPG/MPEG/TXT. etc
PC Operating SystemMicrosoft Windows 10, Windows 7 and XP
Communication TypeNet cable; 3G, WiFi(Sold separately)
CertificateCE, RoHS, FCC, ISO9001, TUV

LED Module& Full waterproof cabinet

High Brightness P10 (P6 P8mm) SMD Full Color Outdoor Advertising LED Screen
1)This cabinet of SMD outdoor LED display can be make up large advertising LED wall with great advertising effect.
2)It's suitable for stage, bank, promotion, exhibition, station, KTV, stadium, airport and all outdoor places.
3)Ultra-thin cabinet and modular design can save install and maintain cost for you and also improve work efficiency.
4)Reasonable PCB design and new plastic cover with new mold improve the quality of LED modules.
5)Adopted MBI constant current driver which can make refresh rate up to 1000Hz load with single receiving card in one cabinet.
High quality product ensure stable and clear image output.
6)Special waterproof design protect your product out of water, the high quality is worthy of trust.
7)The Outdoor SMD LED Display features LINSN control system which ensures great quality output,
high resolution display, fast loading time and high refresh rate.

Control system

High Brightness P10 (P6 P8mm) SMD Full Color Outdoor Advertising LED Screen


Outdoor P10 LED Display Full Color LED Modules LED Screens

Outdoor P10 LED Display Full Color LED Modules LED Screens

Our Service
1) Your inquiry related to our products or price will be replied in 24 hours
2) Well-trained and experienced staffs to answer all your enquires in fluent English
3) OEM&ODM, any your customized screen we can help you to design and put imto product.
4)Distributoer ship are offered for your unique design and some our current models.
5)Protection of your sales area, ideas of design and all your private information

Trade Terms
1) Payment:T/T, usually 30% prepayment before production, 70% balance to be paid before delivering, it also change according to total quantity
2) Production lead time less 20sqm:7-15 days, more than 50 sqm:30 days
3)Sample can be delivered in 30 days
4) Shipping port: Shenzhen, Mainland China
5) Discounts are offered based on order quantities
6) MOQ:1sqm/1pcs

1. Free training:
You can send your engineers who have knowledge of electronics and information to our factory and we provide free technical training, which contains training operation and maintenance of the LED display at our factory. We also offer the instruction manual, software, test report, drawing steel structure and so on.

2. Installation:
We offer you the engineer to install the LED display, you have to offer him the two-way air tickets and accommodation as well as visa. The engineer's salary is $80/day; Or we offer you the training on the LED display installation and repairing for free after you live in our company, or we can guide you to install the screen by remote control.

3. Service after sales:
If you have any questions about our product, you can inform us by mail or call, and we will reply you in 24 hours when we get you E-mail or call, and offer you a good solution for your problem
