P4.81 Outdoor interactive LED floor display application

The dance floor detail specification
The feature for the Interactive Floor Display | LED Video Floor | Dance Floor LED Display
1 .High Load Bearing with 2T weight


Anti scratch Mask with HI-density PC




3 Easy assemble Special driving IC built inside the LED display PCB will work together with interactive control system.
It will easily and quickly make you interesting and attractive between the players and display.

Packing and loading


The dance floor detail specification
Type Name | Dance floor led display 500 x1000 serial | ||
Pixel Pitch | 3.9mm | 4.8mm | 6.25mm |
Pixel density(dot/m2) | 65400 | 43264 | 25600 |
Brightness (nits) | ≥5500 | ≥5500 | ≥6000 |
Drive Method | 1/16 | 1/13 | 1/10 |
Refresh rate (HZ) | ≥1200 | ||
Cabinet pixel | 128x256 | 104x208 | 80x160 |
Cabinet size (mm) | 500x1000x80 | ||
Loading weight | 2 000KG | ||
Cabinet material | Steel cabinet | ||
Cabinet weight | 18kg/cabinet | ||
Screen work Voltage (V) | 110~240V/AC | ||
Screen power consumption (W/) | Max 750 / Average250 | Max 800 / Average350 | Max800 / Average 320 |
Screen View angle | 140°/140° | ||
IP Grade | IP65 | ||
Operationg Temperature/Humidity | -20~50ºC 10~90% RH | ||
Storage Temperature/Humidity | -40~60ºC 10~90% RH | ||
Life Time | >50000H | ||
Standard Certification | CE CCC | CE CCC | CE CCC |
