P4mm High Definition Advertisement LED Display Indoor Large LED Screen * Slim designNarrow frame design ,cabinet thickness only 80mm, more easy carry and light cabinet only 13kg,easy to install and transportation costs saving. * High Gray Scale & HDR Processing Technology *Front &  Rear maintain scree

Featured Products

P4mm High Definition Advertisement LED Display Indoor Large LED Screen

* Slim design
Narrow frame design ,cabinet thickness only 80mm, more easy carry and light cabinet only 13kg,easy to install and transportation costs saving.
P4mm High Definition Advertisement LED Display Indoor Large LED Screen


* High Gray Scale & HDR Processing Technology

P4mm High Definition Advertisement LED Display Indoor Large LED Screen
*Front &  Rear maintain screen
Small footprint , no need maintenance channel , a step to solve the problem of the installation space question
No need to remove the screws, maintenance speed increase of 10 times than traditional way save your time and workers.

P4mm High Definition Advertisement LED Display Indoor Large LED Screen
P4mm High Definition Advertisement LED Display Indoor Large LED Screen
P4mm High Definition Advertisement LED Display Indoor Large LED Screen

SPECIFICATION

OPTICALPixel PitchmmP4
LED No. Per Pixelpcs/pixel1
Brightness(Adjustment)cd/m²                     1000nit
Cabinet Resolutiondots180*180
Pixel Densitydots/sqm62,500
Viewing Angle(H/V)degreeH140/ V140
Color Depth/Numberbit14bit
Grey Scale-14bit
ELECTRICALFrame Frequency  Hz/s≥60
Refresh RateHz960
Max Power ConsumptionW/m²700
Ave Power ConsumptionW/m²255
Working VoltageAC AC110-220 V
Drive VoltageDC5V
Working TemperatureºC0-40
Humidity-10%-90%
MECHANICALFrame Material-Aluminum
Net Weightkg/pcs22
Weight Per Tilelbs48.54
Cabinet Sizemm720*720
Optimum Viewing Distance4-12m
IP Rating(Front/Rear)-IP43
Lifetime hours100,000
Application-Indoor

P4mm High Definition Advertisement LED Display Indoor Large LED Screen
P4mm High Definition Advertisement LED Display Indoor Large LED Screen
