P5mm Outdoor LED Display for OOH Advertising Outdoor Full Color LED Video Screen

5.0mm pixel pitch LED display, 6,500 nits brightness, 1920Hz+ refresh rate, out of home Advertising LED Video Screen

  • Outdoor advertising LED screen
  • Rugged reliability combination design
  • Outdoor SMD full colour
  • Rent or fixed installation application

Silu`s P5mm Outdoor LED Display is a 5mm pixel pitch outdoor LED video screen for rental or fixed installation occasions. The P5mm outdoor LED screen delivers an excellent visual experience when the viewing distance is more than 5m. With years of development, Silu has accumulated rich experiences and professional technology in the P5mm outdoor advertising LED display manufacturing and P5mm outdoor rental LED screen is becoming more and more mature and stable.

Silu`s P5mm Outdoor LED Display is well-known for its high performance, excellent product quality and our perfect after-sale service, this outdoor LED display products are exported to more than 15 countries and regions, it has been well-received and appreciated by the users.

P5mm Outdoor LED Display LED Module Configuration

  • Top Level Famous Brand SMD2727 LED Lamps
  • 2 Layers 1.6mm Thickness Class-A PCB
  • CH2038S or MBI5124 Performance Driving ICs
  • Strictly Selected Module Frame and Mask
  • Integrated Quality Management System

P5mm Outdoor LED Display for Advertising Outdoor Full Color LED Video Screen


*P5mm Outdoor LED Display LED Module Pic. 01*

P5mm Outdoor LED Display for Advertising Outdoor Full Color LED Video Screen


*P5mm Outdoor LED Display LED Module Pic. 02*

P5mm Outdoor LED Display LED Cabinet Configuration

  • Die-Casting Aluminum Material Frame (Rental or Fixed)
  • Steel or Aluminum Material Cabinet (Fixed)
  • Meanwell Power Supply
  • Nova or Colorlight Receiving Card* (Option)
  • Pure Copper Wire Cables
  • IP65/IP67 Grade Waterproof

P5mm Outdoor LED Display for Advertising Outdoor Full Color LED Video Screen


*P5mm Outdoor LED Display LED Panel Pic. 01*

P5mm Outdoor LED Display for Advertising Outdoor Full Color LED Video Screen


*P5mm Outdoor LED Display LED Cabinet Pic. 02*

    P5mm Outdoor LED Display Description

    Silu`s P5mm Outdoor LED Display presents a dramatic step forward for outdoor LED video wall and advertising operators. The LED display features unique black package screen face technology for incredible contrast levels, stunning image quality and extremely wide viewing angles without colour shift. By using 3-in-1 LEDs, our display delivers minimum viewing distance meanwhile the mechanical design offers you the flexibility to create a screen to suit your size requirements and deliver seamless images without alignment problems. The module construction makes installation easy with pre-assembled and framed panels to fit within your chosen location.

    An Affordable and High-Quality LED Display Solution

    With a simple and endured but strong design, the P5mm outdoor LED screen brings you a very high-quality video wall product while respecting your budget.

    Excellent Heat Dissipation Performance

    On the back cover of the LED cabinet, the P5mm outdoor LED display cabinet equipped with a high-quality cooling fan to make the LED display with better heating diffusion and endurance to ensure the LED display keeps a long time operation.

    High Flatness Seamless Splicing

    Fast lock design to make P5mm outdoor LED display with the features of high flatness, gapless connection, seamless splicing, quick installation, easy dismantling and assembling.

    Excellent Visual Effects

    Ultra-high dynamic contrast and high-quality display, ultra-high-definition perfect picture quality, easily attract attention, greatly enhance the value of advertising, bring you unprecedented visual enjoyment.

    Virtual Pixel and Cloud Control Performance

    The resolution is able to increase 4 times with the same amount of LEDs, it is supporting remote wireless and 3G/4G control management, one monitor centre is able to control several LED Displays by only one computer. New LED video control system does not only have backup systems for power and data. It also provides related spare parts which are designed as ready modules for fast and easy maintenance, the system can automatically switch to the back-up system.

    Economical and Power Saving Display

    Silu`s P5mm outdoor LED display is much more environmentally friendly and energy-saving. The intelligent environment sensor (multi-function card) can adjust the brightness of the LED display automatically according to the around of light around the display. Meanwhile, the lower voltage constant current driving IC saves over 30% power energy. Compared with traditional LED display, our newly designed energy saving LED display is more cost effective to operate and has better visual images.

    IP65 Grade and Waterproof Cabinet Design (up to IP67)

    The unique waterproof design is highly dustproof and waterproof and also it is able to be directly installed on outdoor occasions. The special design structure of P5mm outdoor LED display is exterior with IP65/IP67 grade and the cabinets are moisture and corrosion-proof to work in all weather conditions.

    P5mm Outdoor LED Display Specification

    P5mm Outdoor OOH LED Display
    Pixel Pitch5.0mm
    LED BrandEpistar or Cree* or Nichia*
    Pixel Configuration1R1G1B
    Pixel Density40,000 Pixels/m²
    LED Module320mm x 160mm (12.6" x 6.3")
    64 pixels x 32 pixels
    LED Cabinet640mm x 640mm (25.2"x25.2") or 960mm x 960mm (37.8"x37.8")
    (128 pixels x 128 pixels or 192 pixels x 192 pixels)
    Material: Steel or Aluminum
    Steel: < 26Kg or 45Kg (< 57.2 Lbs or 99 Lbs)
    Aluminum: < 18Kg or 36Kg (< 39.6 Lbs or 79.2 Lbs )
    Working VoltageAC220V±10%; AC110V±10%
    Power ConsumptionAverage 460W/m² / Max 976W/m²
    Maximum Brightness> 6,500 cd/m²
    Refresh Frequency> 1920Hz/S
    Change Frame Frequency60Hz~ >60Hz
    Drive Mode1/8 Scanning
    Total Colors281 Trillion Colors
    Grade LevelRGB 4096 Grade
    Best Viewing Distance5m~>200m (16ft~>650ft)
    Best Viewing AngleHorizontally 140° / Vertically 120°
    Screen Lifetime> 100,000 hours
    Protection LevelFront IP65 / Rear IP54
    Control System ¹Simple LED Video Control System or Advanced LED Video Processor
    Ambient Temperature-40°C ~ 60°C (-30°F ~ 150°F)
    Relative Humidity10%~90%
    Input SignalRF S-Video RGB RGBHV YUVYC etc.
    Brightness Adjustment256 levels of each colour (RGB) can be adjusted manually and 8 levels of each colour can be adjusted automatically. Optional control system: 256 levels of each colour can be adjusted 100% automatically. (8bit / 16bit / 18bit / 24bit)
    Package MaterialWooden Case / Flight Case
    Warranty ³3 Years (5 Years for Cree and Nichia)
    1. WIFI/LAN/WAN/3G/WIMAX control system is available upon request.
    2. The intelligent multifunctional card is available with an automatic brightness sensor to save energy including an outside temperature sensor.
    3. Three years warranty extension program available for OOH Advertising P5mm Outdoor LED Display.
