P10mm outdoor LED display best-selling outdoor advertising LED video screen panel

10.0mm pixel pitch LED display, 6,500nits+ brightness, 1920Hz+ refresh rate, popular sell outdoor advertisement LED video screenOutdoor Advertisement LED video screenFeatures a rugged reliability cabinet designOutdoor high-quality SMD3535 LED lampDesigned for fixed outdoor installation24*7 hours performanceSilu`s P10mm Outdoor L

Featured Products

10.0mm pixel pitch LED display, 6,500nits+ brightness, 1920Hz+ refresh rate, popular sell outdoor advertisement LED video screen

  • Outdoor Advertisement LED video screen
  • Features a rugged reliability cabinet design
  • Outdoor high-quality SMD3535 LED lamp
  • Designed for fixed outdoor installation
  • 24*7 hours performance

Silu`s P10mm Outdoor LED Display is rugged, IP65+ rated waterproof and dustproof solution that deliver high-resolution images with unequalled brightness and contrast levels. This 10mm pixel pitch full colour LED display generates the perfect picture at all times, even in direct sunlight. The best and minimum viewing distance of this P10mm outdoor advertisement LED display is 10 meters.

With the features of long visibility, attractive looking, stability operate and install, Silu`s P10mm outdoor LED video screen has been widely used in traffic road, supermarket, sport-games stadium, School and parks etc. to inform message and graphics.

P10mm Outdoor LED Display LED Module Configuration

  • Famous Nationstar/Cree*/Nicha* SMD3535 LED Lamps
  • 2 Layers 1.6mm Thickness Class-A PCB
  • MBI5124 Performance Driving ICs
  • Private Double Backups Signal and Power Connectors
  • Front and Back Access Service Possibility*

P10mm Outdoor LED Display Popular Sell Outdoor Advertisement LED Video Screen Panel

*P10mm Outdoor LED Display LED Module Pic. 01*

P10mm Outdoor LED Display Popular Sell Outdoor Advertisement LED Video Screen Panel

*P10mm Outdoor LED Display LED Module Pic. 02*

P10mm Outdoor LED Display LED Cabinet Configuration

  • Steel or Aluminum Material LED Cabinet
  • 960mmx960mm Standard Panel Size
  • Meanwell 5V60A Power Supply
  • Nova or Colorlight Receiving Card* (Option)
  • Pure Copper Wire Cables
  • IP65/IP67 Grade Waterproof

P10mm Outdoor LED Display Popular Sell Outdoor Advertisement LED Video Screen Panel

*P10mm Outdoor LED Display LED Cabinet Pic. 01*

    P10mm Outdoor LED Display Description

    Silu`s P10mm Outdoor LED Display comes in a rugged and reliable waterproof LED cabinet with a shared power supply and controller and only four alignment points. In this way, it offers more flexibility and significantly shortens installation and alignment time, and dramatically reduces weight. Thanks to it's signal and power double backups functions, IP65+ rating, and outdoor SMD technology, the P10mm outdoor LED display is designed for fixed installation in 24*7 outdoor branding and advertising.

    High-Quality SMD3535 LED Lamps

    Silu chooses the high reliable and high contrast Nationstar-brand LED lamps to ensure the P10mm outdoor LED display excellent performance, wide view angle and good consistency which meet the needs of high-brightness, 1920+ Hz refresh rate, 65536 levels grayscale and display keeping natural colour at one time with best colour uniformity and fidelity.

    Unique Cost-Reducing Design

    The Silu`s P10mm outdoor LED display`s unique design eliminates the need for a custom-calibrated secondary steel structure which is required for conventional tile-based LED screens. Built on self-supporting and scalable cabinets, it is directly fastened onto the main attachment points, which significantly cuts the cost of installation and the steel structure.

    Easy Install

    A limited set of components allows you to build modular cabinets of the size 960mmx960mm of up to 3x6 LED modules, with each cabinet measuring less than 130mm in depth and fully made of steel or aluminium, the high performance P10mm outdoor LED display can be installed to any of building exterior wall and single or double upright columns and cables can easily be accessed from the side of LED cabinet as well as the built-in without exposed type.

    Well-Known Meanwell Brand Power Supply

    All series outdoor fixed installation LED display is adopting Meanwell power supply, electro-optic conversion ratio up to 82%, low heat dissipation and long life span.

    Revolutionary Processing

    As well as next to offering outstanding image quality, Silu`s P10mm outdoor advertisement LED Display also comes with the revolutionary image processing platform. It excels in pixel bandwidth performance and combines this with fully cloud-based monitoring, control and automated diagnostics.

    Other Key Benefits

    • Excellent image quality, wide viewing angles
    • Lowest weight in its class
    • Minimum installation costs
    • No precision supporting steel required
    • Ultimate reliability
    • Easy front AND back access*
    • Advanced web-based setup, monitoring and control

    IP65 Grade and Waterproof Cabinet Design (up to IP67)

    The unique waterproof design is highly dustproof and waterproof and also it is able to be directly installed on outdoor occasions. The special design structure of P10mm outdoor LED display is exterior with IP65/IP67 grade and the cabinets are moisture and corrosion-proof to work in all weather conditions.

    SMD outdoor P10mm LED Display is widely used at Airport, Station, Roadside, Shopping Mall centre as a high-efficiency advertising and promotion way.

    P10mm Outdoor LED Display Specification

    P10mm Outdoor Advertisement LED Video Display
    Pixel Pitch10.0mm
    LED BrandEpistar or Cree* or Nichia*
    Pixel Configuration1R1G1B
    Pixel Density10,000 Pixels/m²
    LED Module320mm x 160mm (12.6" x 6.3")
    32 pixels x 16 pixels
    LED Cabinet640mm x 640mm (25.2"x25.2") or 960mm x 960mm (37.8"x37.8")
    (64 pixels x 64 pixels or 96 pixels x 96 pixels)
    Material: Steel or Aluminum
    Steel: < 28Kg or 45Kg (< 61.6 Lbs or 99 Lbs)
    Aluminum: < 21Kg or 36Kg (< 46.2 Lbs or 79.2 Lbs )
    Working VoltageAC220V±10%; AC110V±10%
    Power ConsumptionAverage 456W/m² / Max 960W/m²
    Maximum Brightness> 6,500 (10,000+) cd/m²
    Refresh Frequency> 1920Hz/S
    Change Frame Frequency60Hz~ >60Hz
    Drive Mode1/2 Scanning
    Total Colors281 Trillion Colors
    Grade LevelRGB 65536 Grade
    Best Viewing Distance10m~>500m (32ft~>1600ft)
    Best Viewing AngleHorizontally 140° / Vertically 120°
    Screen Lifetime> 100,000 hours
    Protection LevelFront IP65 / Rear IP54
    Control System ¹Simple LED Video Control System or Advanced LED Video Processor
    Ambient Temperature-40°C ~ 60°C (-30°F ~ 150°F)
    Relative Humidity10%~90%
    Input SignalRF S-Video RGB RGBHV YUVYC etc.
    Brightness Adjustment256 levels of each colour (RGB) can be adjusted manually and 8 levels of each colour can be adjusted automatically. Optional control system: 256 levels of each colour can be adjusted 100% automatically. (8bit / 16bit / 18bit / 24bit)
    Package MaterialWooden Case / Flight Case
    Warranty ³3 Years (5 Years for Cree and Nichia)
    1. WIFI/LAN/WAN/3G/WIMAX control system is available upon request.
    2. The intelligent multifunctional card is available with an automatic brightness sensor to save energy including an outside temperature sensor.
    3. Three years warranty extension program available for 10mm pixel pitch full-colour P10mm Outdoor LED Display.
