P1.9 Indoor HD Full Color LED Display
LED Light
| LED | LED Lamp | LED Type | Wavelength(nm) | Average Brightness | Test Condition |
| RED (R) | Jingyuan | SMD 1515 | 620-625nm | 130-190mcd | 25ºC,20mA |
| GREEN(G) | Huacan | 520-525nm | 200-300mcd | 25ºC,10mA | |
| BLUE(B) | Huacan | 470-475nm | 23-40mcd | 25ºC,5mA |
.Pixels/Modules
| No | Serial | Parameters |
| 1 | Pixel Pitch | 1.9mm |
| 2 | Pixel Configuration | 1R1G1B R:G:B=3:6:1 |
| 3 | LED Lamp | Full Color |
| 4 | Density | 277008 dot/m2 |
| 5 | Module Size | 152x171mm |
| 6 | Module Pixel | 80*90=7200 dot |
| 7 | Module Thickness | 15mm |
| 8 | Module Weight | 108g |
| 9 | Module Power | ≤2.6W |
| 10 | Driving Voltage | DC5V |
| 11 | Module Current | 0.52A |
| 12 | Module Interface | HUB-75D/B |
Screen Parameters
| No | Serial | Technic Parameters |
| 1 | Standard Cabinet Size | 608mm*342mm*75mm (16:9) |
| 2 | Single Cabinet Weight | 5.35KG |
| 3 | Brightness/Adjustment | ≥600cd/m2 (With Current Gain Function, Adjustment 100-600CD) |
| 4 | View Angle | ≥140°(Horizontal),≥140°(Vertical) |
| 5 | Best View Distance | ≥2m |
| 6 | Grey Level | ≤65536 |
| Color Temperature | 8000K | |
| 7 | Frame Frequency | ≥60Hz |
| 8 | Refresh Rate | ≥2400Hz |
| 9 | Signal Input/ Control Mode | Video,VGA/Computer Control,Video Synchronization,Real time Display |
| 10 | Driving Mode | 1/32 Scan |
| 11 | Driving IC | 6902 |
| 12 | Module Quantities/ Sqm | 38 |
| 13 | Display Colors | 16777216 |
| 14 | Continue Working Time | >24(Hrs) |
| 15 | Screen Lifespan | >100,000(Hrs) |
| 16 | MTBF | >5000(Hrs) |
| 17 | Max Power Consumption | 60-100W/m2 |
| 18 | Average Power Consumption | 20-33W/m2 |
| 19 | Blind Point Rate | ≥3/10,000(Discrete Distribution) |
| 20 | Control Distance | 100mRepeat Less Cable) 500m(Multi-mode Fiber) 10km(Single-mode Fiber) |
| 21 | Surface Flatness | Screen Flatness error≤0.5mm,Pixel Pitch error≤0.3mm |
| 22 | Working Temperature | -10ºC~+50ºC |
| 23 | Working Humidity | 10%~98%RH |
| 24 | Storage Temperature | -40ºC~+85ºC |
| 25 | Software Interface | Standard Computer Interface,Compatible with Windows,Unix,Novell |
| 26 | Protection System | Overheat, Overload,Power Failure,Image Compensation,Gamma Correction |
| 27 | Working Voltage | 200~240 V |
| 28 | Dielectric Strength | 50HZ/1500V(ac RMS)/1min |
| 29 | Temperature Rise | Metal≤40K,Insulation≤65K after heat balance |
| 30 | IP Grade | IP43 |
| 31 | Dielectric Strength | 50HZ/1500V(ac RMS)/1min |
| 32 | Computer Display Mode | 1024*768 |
| 33 | Playing Software | LED Professional Player |
