P3.91 Window Shop Transparent Led Screen
1.Main Features And Functions
Transparent LED display series is specially designed for windows advertising and building facades, which has high transparence, HD resolution for brand marketing and advertising, this series led display is very light weight, panel thickness only 60mm to ensure the less space during installationHigh Transparence
70%-85% transparence
HD Resolution
High resolution,P3.91-P16mm
Thin & Light Weight
60mm thickness,5-7KG each panel
Energy Saving
30% lower consumption than traditional led display series.
High Refresh Rate
Good refresh rate for events and shops
Easy Installation
Standard connector,hang,or stack-up,convenient.
2. Main Technical Specifications
| PARAMETERS | DESCRIPTION |
| Brightness | ≥3000 Nits |
| Viewing angle | H: 120°; V: 120° |
| Panel weight | 7kg |
| Panel size | W500mm x H1000mm |
| Panel material | Aluminum |
| Ingress protection | Front/Rear: IP43 |
| Operating Temperature/Humidity | -20ºC - +50ºC/ 10-90%RH |
| Storage Temperature/Humidity | -40ºC - +60ºC/ 10-90%RH |
| Pixel configuration | 1R1G1B |
| Pixel Pitch | 3.91mm-7.81mm |
| Pixels per panel | 128x128Dots |
| Physical density | 32768pixels / m 2 |
| Recommended viewing distance | 4M |
| Color | 4.4 trillion |
| Gray scale | 65536 levels per color |
| Brightness control | 256 levels of each color(manually),8 levels of each color(automatically) |
| Contrast ratio | 1000:1 |
| Processing depth | 16bits |
| Video frame rate | 1920Hz |
| Input voltage | 110-220VAC+-10% |
| Input power frequency | 50-60Hz |
| Input power <max> | 450watts |
| Input power <typical> | 160watts |
| Life Time | ≥100,000 Hours |
| LED Wavelength | R:620-625nm G:525-529nm B:472-478nm |
| Driving Method | 1/16 scan |
| LED Encapsulation | SMD1921 |
| Input signal | RF,S-VIDEO,RGBHV,YUV,YC & COMPOSITION, etc |
| Certifications | CCC,CE,FCC,ETL,IP65,EMC |
3. Application
LED transparent screen to retain the traditional LED display with easy control, low voltage DC drive, the combination of rich color performance, long life and other advantages at the same time. But also because of its unique advantages in the application of glass curtain wall, is widely used in urban lighting engineering, large-screen display system. At the same time can be used as indoor display curtain wall, is widely used in large-scale square lighting, stage sets, bars, high-end dance halls, urban landmarks, municipal buildings, airports, cars 4S shops, hotels, banks,
brand chain, Glass display both the practicality of the display, but also a certain degree of beauty and concealment.
