Bracket LCD TV Video Wall Processor Digital Information Display Video Wall LCD Monitor

stand lcd tv video wall processor Digital Information Display video wall lcd displayProduct Description       Product Description for  Top Adkiosk original Korea 46 inch super narrow bezel lcd video wall with video wall controller LCD Video Wall Screen (SAMSUNG DID)SpecificationsModel

Featured Products

stand lcd tv video wall processor Digital Information Display video wall lcd display
Product Description

       Product Description for  Top Adkiosk original Korea 46 inch super narrow bezel lcd video wall with video wall controller

LCD Video Wall Screen (SAMSUNG DID)
Specifications
Model No.TPK-VW4601
Panel Size46'' Samsung DID LCD Screen(super narrow bezel 5.3mm)
Aspect Ratio 16:9
Max Resolution Support1920x1080/1366x768
 Color8Bit,16.7M
Brightness (nits)450
Contrast 4000:1
Visual Angle (H/V)178°
Response Time<=6ms
Life(hrs)>60,000(hrs)
Input and output
DVI1
HDMI1
D-15 RGB Input(VGA)1
YUV/YPbPR1(3xBNC)
S-(YC)1(2xBNC)
Composite Video Input/(AV)3(3xBNC)
Composite Video Output2(2xBNC)
AUDIO INPUT1
Split ScreenSupport Picture in Picture(PIP/POP/PAP)
Power
Power SupplyAC100V~240V
Maximum Power Consumption250W
Standby Power Consumption<=3W
Temperature
Working Temperature0°C~50°C
Working Humidity20%-80%
Dimension1025.65x579.84x126.73mm
Video Wall Controller(Built-in each Screen)
Model No.US-P816A
Input CVBS3*BNC inputs, support PAL/NTSC all formats, 2*BNC loop outputs
VGA1*D15 port, support SVGA/XGA/WXGA
YPbPr/YCbCr1* YPbPr/YCbCr input, support PAL/NTSC all formats, and 720P,1080I, HDTV
Y/C2*BNC inputs, support PAL/NTSC all formats
Output LVDSSupport signal or double LVDS output, and WUXGA (1920*1080) display
Operate  mode Panel key operation(needs customization)
Standard RS232 port( provide free control software)
Infrared Remote Control Operation
 Engineering softwareCustomized
Working temperature  0~70 °C
working humidity5~95 %RH
AC voltage power supply100-240V/50, 60Hz
power consumptionMax 300W,according to different Screen models
Dimension338×295×60(mm)
WeightAbout 3.5KG
Stand LCD TV Video Wall Processor Digital Information Display Video Wall LCD Display
Stand LCD TV Video Wall Processor Digital Information Display Video Wall LCD Display
Stand LCD TV Video Wall Processor Digital Information Display Video Wall LCD Display

Stand LCD TV Video Wall Processor Digital Information Display Video Wall LCD Display
Stand LCD TV Video Wall Processor Digital Information Display Video Wall LCD Display
Stand LCD TV Video Wall Processor Digital Information Display Video Wall LCD Display

Stand LCD TV Video Wall Processor Digital Information Display Video Wall LCD Display

Stand LCD TV Video Wall Processor Digital Information Display Video Wall LCD Display
Stand LCD TV Video Wall Processor Digital Information Display Video Wall LCD Display


Stand LCD TV Video Wall Processor Digital Information Display Video Wall LCD Display



Stand LCD TV Video Wall Processor Digital Information Display Video Wall LCD Display
Shenzhen Top Adkiosk is highly specialized in the field of LCD Digital Signage products. We have developed our own LCD products Series, such as digital signage, all In One PC, touch screen, lcd video wall, outdoor IP65 High Brightness LCD Digital Signage and TV, etc, the size is available with 17 Inch to 110 Inch etc.
   These products have been widely used in the USA, Europe, Southeast Asia, the Middle East, Africa and other countries and regions. These products are suitable for advertising in lots of areas, such as buildings, shops, hotels, supermarkets, railway stations, bus stations, airports, taxis, buses and other outdoor areas.
   Quality and Service is Our Symbol.The most important factor for us to win our customers' hearts and found the long-term business relationships with our customers is quality and service. With these years' research, development and manufacture, we have accumulated our special experience and methods to control the quality through the whole process of designing, material purchasing, manufacturing and marketing. Especially for the material quality, we have founded firm relationships with our suppliers and even invested in some supply companies to directly control quality. We offer 7*24 hours service to all our clients. Our sales person and after-selfteam will keep on line to answer and solve all questions for you.
Providing services beyond our customers' expectations is our purpose. Our excellent pre-sales services and after-sales services have earned us many customers' hearts.
