P5 High Definition LED Wall Screen Rental Digital LED Display


Quick Detail:

1, Lightweight - weighs only 8kg, single person can be a single portable, and extremely easy to install;
2, Thin - box with die casting aluminum, high-strength, high toughness, high precision and difficult to deformation, for the transport of effort;
3, High-precision - accurate to size of the electrical and mechanical processing 0.1mm;
4 Compatible - the new structure designed to meet the lifting, stacking requirements to meet the indoor and outdoor requirements;
5, Fast - up and down box connected by quick-locking mechanism, 10 seconds to complete a cabinet installation, the installation of high accuracy;
6, Reliable - high strength hardness, good heat dissipation;
7, Cost - light weight housing, low cost of installation required; low power box, save operating costs and reduce labor costs.
8. Indication lights to show status of power and signal status
9.Fast cooling: excellent heat dissipation performance to protect the module circuit
10.High precision: seamless splicing though CNC machine

Specification

ModelBST-P5-I
Pixel Pitch5mm
Unit Size480mmx480mm
LED TypeSMD3528
Pixel / Unit96*96
Unit Weight7kg
Viewing Angle(H/V)140°/140°
ApplicationStorage-40~60° C,   Working-20~50° C
Protection Level(Front/Rear)IP40/IP21
Power Consumption(AVG.)240w/m2
Driving1/8 Scan
Frame Refresh≥ 60Hz
Data Refresh Rate>1500Hz
Processing16bit
Brightness>1200nits
Power SupplyAC 110/220±10%,  50~60Hz
MTBF≥ 1, 000 Hours
Life Span≥ 100, 000 Hours
Pixel Failure< 0.0003

P5 High Definition LED Wall Screen Rental Digital LED Display
P5 High Definition LED Wall Screen Rental Digital LED Display

P5 High Definition LED Wall Screen Rental Digital LED Display

P5 High Definition LED Wall Screen Rental Digital LED Display
P5 High Definition LED Wall Screen Rental Digital LED Display
P5 High Definition LED Wall Screen Rental Digital LED Display

Why choose BST high brightness LED module ?
1.We have specilsed in indoor&outdoor LED display and LED display modules for 8 years.

2.We are the manufacturer and wholesaler for LED display, LED display module and LED accessories. We can control the quality and save cost.

3.100% QC inspection before Shippment.

4.CE,FCC,ROHS,CCC,ISO9001 certification approved, assure high quality.

What we can offer you?
1.Before delivery
We will test the display, and keep it light up for 72 hours, and check all the parts of thedisplay to confirm it is Ok for delivery.

2.Delivery (Time)
FOB Shenzhen (approx 20 working days after the advanced payment)

3.Service after sales
If you have any questions about our product, you can inform us by mail or call, and we will reply you in 24 hours when we get you Email or call, and offer you a good solution for your problem.

4.Warranty
Two year quality warranty.


Why choose BST?
  1. BST is a professional manufacturer of LED display screens over 8 years. We have strong R&D to ensure high end products with user-friendly design .
  2. The prices are very competitive due to our large-scale procurement of raw material.   We can help you to win more orders if you are distributors.End users will also be satisfied with our quality and price.
  3. We have CE, FCC and Rohs certificates. Our products are exported over 85 countries .We have rich experience in handling all possible problems when you import goods from China .
  4. We have a wide variety of products for you to choose from .All products are strictly tested before release to market and we test every LED screen 72 hours before delivery.
  5. Our sales are well trained to offer professional advice on your specific projects. Processional engineers are on standby, can offer guidance, on site technical support as requested.
  6. We offer 2-3 years warranty and life time maintenance .Even when warranty time expires , we only charge material costs
